103-097 52717 Balboa ® | 103-097 Coleman® Circuit Board

Balboa ® Spa circuit board part number 52717 for Colemans® Spas part number 103-097 - replaced with 103-097

Features:

Chip Number: 630R1A, 630R1B, 630R1C
630 Circuit Board for Eprom Revisions 630R1A, 630RIC, 630R2B

Product specifications:

8 Pin Phone Cable

Used in Power Works Balboa 52716 Control System. Replaces versions 630R1, 630R1A and 603R1B. Use control panel 103305 along with the overlay 103306. If system has a blower, use overlay 103307.

Replaces Balboa 52716-03

Used for 2003 630 Maax Coleman spas and other Coleman spas in the 400 Series Deluxe and Premium between 2003-2005.

Circuit boards are not "plug and play - they will require correct component voltage set-up and dipswitch configuration. Please follow the wiring schematics on the back side of the spa pack cover.

Do not buy a circuit board based on appearance, as many boards look the same and manufacturers can change board appearance. Refer to this tech tip before buying a replacement board What to Look for When Buying a Circuit Board – Spa Parts Experts

SKU: 52717
MPN: 52717
Model: 2000LE M7
UPC: 689145866520
Manufacturer: Balboa®Water Group
Warranty: 1 yr. (with manufacturer)
-----------------------------------------
Shop this and more spa parts at the best prices online at Spa Parts Experts.

Note:

THIS IS A NON RETORNABLE ITEM
Remember that it's very important that you don't order a circuit board based on looks (several boards look alike but have different software or chips)
Some circuit boards come with a large variety of software. Be sure to order the correct one for your needs

As with all electrical items once a circuit board has been installed, we cannot take it back other than for manufacturer's warranty

Disclaimer: The product image displayed is for illustrative purposes only.
The actual product may vary in color, size, shape, or other physical attributes.
We strive to provide accurate product descriptions and images, but please note that the representation of the product may differ slightly from the actual item received.
