0610-221126-728 Gecko® Control System Gecko In.YE-5 V3 4.0kW 115/230v Does not include cords, topside or wifi
Couldn't load pickup availability
0610-221126-728 Gecko® Control System Gecko In.YE-5 V3 4.0kW 115/230v Does not include cords, topside or Wi-Fi
0610-221126-728 Gecko® Control System Gecko In.YE-5 V3 4.0kW 115/230v Does not include cords, topside or Wi-Fi
Features:
• 115V / 230V Convertible (4-Wire)
• Can run up to 3 pumps; compatible with swim spas using dual packs
• Dual-pack configurations can support up to 5 pumps plus circulation pump and ozone system
• 5 Configurable High-Voltage Outputs for Pump 1, Pump 2, Blower, Circ Pump, and Ozonator
• 4.0 kW Integrated Flow-Through Heater with stainless steel construction and dry-fire protection (in.flo)
• V3 Platform with enhanced CPU, external memory, larger-capacity relays, and in.mix 300 color LED support
• Individually configurable output voltages for each component
• Solid-State Water Flow Detection (no pressure switch required)
• IPX5 Waterproof Enclosure with in.seal connector protection
• in.stik OTA software update capability
• Audio-ready and swim spa compatible
• Standard 12 Vdc light output
• Circ pump ready (115V / 230V)
• 2-Year Manufacturer Warranty
Product Specifications:
Control Pack Information
• Control Box Only – Gecko IN.YE-5 Version 3 (V3)
• Part Number: 0610-221126-728
• Keypad Not Included
Electrical Specifications
• Supply Voltage: 115V / 230V (4-Wire Convertible)
• Frequency: 60 Hz
• Number of Outputs: 5 Configurable Relays
Heater Specifications
• Heater Output: 1.0 kW / 4.0 kW
• Heater Dimensions: 2" OD x 15" Length
• Minimum Flow Rate Required: 20 GPM
System Features
• Flow Detection: Solid-State (No Pressure Switch)
• Waterproof Rating: IPX5 (in.seal Technology)
• Light Output: Standard 12 Vdc
Compatible Keypads (Sold Separately Unless Noted)
• IN.K200 — Entry-Level 2-Pump Keypad (BDLK2002OP)
• IN.K300 — Standard 4-Button Dual-Pump Keypad (BDLK3002OP)
• IN.K450 — Mid-Range 3-Pump Multi-Function Keypad (BDLK4503OP)
• IN.K600 — Advanced Static Display Keypad (BDLK6005OP)
• IN.K8 — Compact 8-Button Keypad (BDLK83OP)
• IN.K120 — Auxiliary/Secondary Keypad (0607-005019)
• IN.K800 — Premium Full-Color 10-Button Keypad (0607-008030)
• IN.K1000 — Premium Touchscreen Keypad (0607-005042)
• IN.K1001 — Premium Touchscreen Keypad (0607-008152)
Replaces / Supersedes
• 0610-221046-355 (Discontinued V2 IN.YE-5 Spa Pack)
• 0610-221002A (Older IN.YE-5 Variant)
• 0610-221020 (Older IN.YE-5 Variant)
• Compatible retrofit for most Balboa spa packs and older electro-mechanical systems
Installation Notes
• Two-speed pumps use two of the five available outputs
• When using both a circulation pump and ozonator at different voltages, AMP Splitter Harness 9920-401369 (sold separately) is required
• Wi-Fi control requires IN.TOUCH 3 module (sold separately) and the free Gecko mobile app for iOS or Android
Replaces: 0610-221046-355, 0610-221002A, 0610-221020
SKU: 0610-221126-728
MPN: 0610-221126-728
Model: IN.YE-5 Version 3 (V3)
UPC: N/A
Manufacturer: Gecko Alliance
Manufacturer Warranty: 1 Year
-----------------------------------------
Shop this and more spa parts at the best prices online at Spa Parts Experts.
Disclaimer: The product image displayed is for illustrative purposes only.
The actual product may vary in color, size, shape, or other physical attributes.
We strive to provide accurate product descriptions and images, but please note that the representation of the product may differ slightly from the actual item received.
Note: Manufacturer's warranty does not cover GFCI trips or leaks due to improperly maintained water chemistry.
Share
Frequently Asked Questions
A spa air blower forces air into the spa's air plumbing system to create bubbles through the air jets. This produces the bubbling massage effect many hot tubs are known for and enhances the overall hydrotherapy experience.
No. Some spas use only water jets that mix air through a venturi system. Spas that include a dedicated air blower produce stronger bubbles and a more intense massage effect.
Common signs of a failing spa air blower include: No bubbles coming from the air jets, Loud humming or grinding noises, The blower not turning on, Weak or inconsistent airflow. If your spa previously had strong bubbles and they suddenly stopped, the air blower may need to be replaced.
Spa air blowers are commonly available in 1.0 HP, 1.5 HP, and 2.0 HP models. The correct size depends on the number of air jets and the plumbing length in your spa. Matching the horsepower of your existing blower is usually the best option.
Yes. If water flows backward into the blower it can damage the motor. This is why most spa systems include a check valve in the air line to prevent water from reaching the blower.
A loud blower can be caused by: Worn motor bearings, Debris inside the blower housing, Airflow restrictions in the plumbing, A failing blower motor. If the noise continues to get worse, replacement may be necessary.
Many spa owners can replace an air blower if they are comfortable with basic electrical connections. However, if you are unsure about wiring or spa electrical components, professional installation is recommended.
No. An air blower simply pushes air into the spa plumbing. Some models have heated air features that warm the air slightly for comfort, but they do not heat the spa water.
