G4152 Balboa® Control System VS501Z Spa Control 1.0/4.0kW Flow Thru Heater
Couldn't load pickup availability
G4152 Balboa® Control System VS501Z Spa Control 1.0/4.0kW Flow Thru Heater - 1 pump, with blower.
Balboa® System VA501Z 1 Pump, with blower
***Control Systems and circuit boards are not "plug and play" - they will require correct component voltage set-up and spa configuration. Please see the "Technical and Installation" below for more information. Please also follow the wiring schematics on the back side of the spa pack cover.***
The Value Series (VS) family of hot tub control systems were designed using Balboa’s patented M7 temperature and flow sensor technology and a new universal control platform. These features increase the reliability, ease of installation and serviceability of the control.
Features:
- 2-Speed Pump (x1) - 120V/240V
- 1-Speed Pump (x2) - 120V/240V
- Circ Pump Circuit - 120V/240V (24/7 Circulation)
- Ozone Circuit - 120V/240V
- Light Circuit - 12V
- Topside Control: Not Included.
- Titanium Heater - 120V/240V - 4.0 KW (240V) - 1.0KW (120V)
- Temperature Sensor - Heater Mount - Auto Reset
- Overheat Sensor - Heater Mount - Auto Reset
Product specifications:
- Power Supply: 120/240V (convertible)
- Pump 1: 1-Speed (circ) or 2-Speed
- Pump 2: Blower (1-speed)
- Panel Capacity: 2
Power Requirements:
- 120/240VAC, 60Hz, 16/32A, Class A GFCI-protected service (Circuit Breaker rating = 20/40A max.)
- 3 or 4 wires [hot, hot (optional), neutral, ground].
Replaces: VS501Z
Alternates: 54217, 54220
Documents:
- G4152 Hot sheet
- G4152 Operation guide
SKU: G4152
MPN: G4152
Model: VS501Z
Manufacturer: Balboa Water Group®
Warranty: 1 yr. (with manufacturer)
-----------------------------------------
Shop this and more spa parts at the best prices online at Spa Parts Experts.
Disclaimer: The product image displayed is for illustrative purposes only.
The actual product may vary in color, size, shape, or other physical attributes.
We strive to provide accurate product descriptions and images, but please note that the representation of the product may differ slightly from the actual item received.
Share
Frequently Asked Questions
A spa air blower forces air into the spa's air plumbing system to create bubbles through the air jets. This produces the bubbling massage effect many hot tubs are known for and enhances the overall hydrotherapy experience.
No. Some spas use only water jets that mix air through a venturi system. Spas that include a dedicated air blower produce stronger bubbles and a more intense massage effect.
Common signs of a failing spa air blower include: No bubbles coming from the air jets, Loud humming or grinding noises, The blower not turning on, Weak or inconsistent airflow. If your spa previously had strong bubbles and they suddenly stopped, the air blower may need to be replaced.
Spa air blowers are commonly available in 1.0 HP, 1.5 HP, and 2.0 HP models. The correct size depends on the number of air jets and the plumbing length in your spa. Matching the horsepower of your existing blower is usually the best option.
Yes. If water flows backward into the blower it can damage the motor. This is why most spa systems include a check valve in the air line to prevent water from reaching the blower.
A loud blower can be caused by: Worn motor bearings, Debris inside the blower housing, Airflow restrictions in the plumbing, A failing blower motor. If the noise continues to get worse, replacement may be necessary.
Many spa owners can replace an air blower if they are comfortable with basic electrical connections. However, if you are unsure about wiring or spa electrical components, professional installation is recommended.
No. An air blower simply pushes air into the spa plumbing. Some models have heated air features that warm the air slightly for comfort, but they do not heat the spa water.
