G4223 Balboa ® EL2001M3 Control System, w/4.0kW Flow Thru Heater
This Balboa ® EL2001M3 Control System comes with a 4.0kW Plug-n-Click Heater, Pump #1 (1 or 2 speed), Pump #2 (1 or 2 speed), Pump #3 or Blower, Circulation Pump (min 30 GPM).
***Control Systems and circuit boards are not "plug and play" - they will require correct component voltage set-up and spa configuration. Please see the "Technical and Installation" below for more information. Please also follow the wiring schematics on the back side of the spa pack cover.***
Features:
- 2-Pumps, 230V, 4.0kW
- Plug-n-click heater
- M7 technology
- Can be used with many ML type control panels
Product specifications:
- Supply Voltage: 230V (4 Wire)
- Pump 1: 2 Speed at 120 or 220 Volts (Ships at 220V)
- Pump 2: 1 Speed or 2 Speed, at 120 or 220 volts (Ships at 220V)
- Air Blower / Pump 3: At 120 or 220 Volts (Ships at 220V)
- Circ Pump Ready: Yes
- Circ Pump: At 120 or 220 Volts (Ships at 220V)
- Heater Wattage: 4.0kW (at 220 Volts)
- Ozone: At 120 or 220 Volts (Ships at 120V)
- Light: At 12V only (will not operate Fiber Optic Lighting)
- Topside control not Included
- Keypad: Not Included
- Size: 10-9/16" x12-1/4"x 4-1/2"
- 60Hz
Note: Topside control panel, cords, light bulb, drywell, and light reflector sold separately if needed.
Replaces: EL2001M3 spa packs 55066-04,55066-03, 55066-02 and 55066-01
Alternates: 55066-04,54464-04, BAL55066, BB55066, BAL54464, BB54464
Technical Information:
Documents
- G4223 Configuration guide
SKU: G4223
MPN: G4223
Model: EL2001M3
Manufacturer: Balboa Water Group ®
Warranty: 1 yr. (with manufacturer)
-----------------------------------------
Shop this and more spa parts at the best prices online at Spa Parts Experts.
Disclaimer: The product image displayed is for illustrative purposes only.
The actual product may vary in color, size, shape, or other physical attributes.
We strive to provide accurate product descriptions and images, but please note that the representation of the product may differ slightly from the actual item received.
Share
Frequently Asked Questions
A spa air blower forces air into the spa's air plumbing system to create bubbles through the air jets. This produces the bubbling massage effect many hot tubs are known for and enhances the overall hydrotherapy experience.
No. Some spas use only water jets that mix air through a venturi system. Spas that include a dedicated air blower produce stronger bubbles and a more intense massage effect.
Common signs of a failing spa air blower include: No bubbles coming from the air jets, Loud humming or grinding noises, The blower not turning on, Weak or inconsistent airflow. If your spa previously had strong bubbles and they suddenly stopped, the air blower may need to be replaced.
Spa air blowers are commonly available in 1.0 HP, 1.5 HP, and 2.0 HP models. The correct size depends on the number of air jets and the plumbing length in your spa. Matching the horsepower of your existing blower is usually the best option.
Yes. If water flows backward into the blower it can damage the motor. This is why most spa systems include a check valve in the air line to prevent water from reaching the blower.
A loud blower can be caused by: Worn motor bearings, Debris inside the blower housing, Airflow restrictions in the plumbing, A failing blower motor. If the noise continues to get worse, replacement may be necessary.
Many spa owners can replace an air blower if they are comfortable with basic electrical connections. However, if you are unsure about wiring or spa electrical components, professional installation is recommended.
No. An air blower simply pushes air into the spa plumbing. Some models have heated air features that warm the air slightly for comfort, but they do not heat the spa water.
